Specifications |
Processor |
VIA Eden (V4) / C7 Nano BGA2 400 pin, L1/L2 128K ondie
Front side bus 400/533MHz |
Chipset |
VIA CN700 + VIA VT8237R Plus |
Graphics |
Integrated with VIA CN700
Shared system memory up to 64MB
MPEG-2 hardward VLD
TV-Out (Optional)
NTSC(M, J) or PAL (B,D,G,H,I,M,N,Nc) |
Memory |
1 x DDRII SDRAM 533/400 (Max. 1GB) |
IDE |
Ultra DMA-133/100/66 transfer protocols
1 x 40pins 2.54mm
1 x 44pins 2.0mm
Support Compact Flash card type II for ATA interface |
Audio (Optional) |
AC-Link for Audio CODEC, AC'97 2.1 |
LAN |
4 x Intel 10/100/1000 Mbps (Optional Realtek/Intel Gigabit) |
IO Function |
1 x RS232
Support IrDA, 0/ASKIR protocol
Supports PS2 keyboard and mouse |
USB |
7 x USB 2.0 |
PCMCIA |
Richo R5C812 PCMCIA chipset compliant PCI with ver2.3
Support 2x sockets, for Cardbus (Card 32) and 16bit card |
SATA |
One channel connector
SATA drive transfer rate is capable of up up 150MB/s |
DIO/WDT (Optional) |
Hardware digital input & output, 4xDI / 4xDO
Hardware Watch Dog Timer, 0~255 sec programmable |
Expand Interface |
1 x Mini PCI for only PCI rev: 2.2 interface
1 x PCI gold finger (share with Mini PCI) |
Power |
On board DC+12V convert to +3.3V/+12V/+5V for system |
Power Management |
Power Loss Resume Feature |
Operation Temperature |
0 ~ 60C |
Operation Humidity |
5 ~ 95% @ 60C, non-condensing |
OS Support |
Windows XP
Windows 2000
Windows Vista
Windows 7 (32 Bit)
Windows 20003 Server
Windows 2008 Server
Ubuntu
Fedora
Centos
Debian
RedHat
|
Resolution |
Support 16:9 Resolution, but not 1080p HDTV
Maximum Resolution 1920 x 1440 32-bit 75 Hz |
